General information
Type	Transport aircraft / Turboprop Regional airliner
National origin	Soviet Union
Manufacturer	Antonov
Status	In limited service
Primary users	UTair Cargo Angara Airlines IrAero Yakutia Airlines Air Koryo
Number built	1,367 (including the Chinese Y-7)
History
Manufactured	1959–1979
Introduction date	1962
First flight	29 October 1959
Variants	Antonov An-26 Antonov An-30 Antonov An-32
Developed into	Xian Y-7

The

Antonov An-24 (Russian/Ukrainian: Антонов Ан-24) (NATO reporting name: Coke) is a 44-seat twin turboprop transport/passenger aircraft designed in 1957 in the Soviet Union by the Antonov Design Bureau and manufactured by Kyiv, Irkutsk and Ulan-Ude Aviation Factories.

First flown in 1959, the An-24 was produced in some 1,000 units of various versions; in 2023 there are 93 still in service worldwide, mostly in the CIS and Africa. It was designed to replace the veteran piston Ilyushin Il-14 transport on short to medium haul trips, optimised for operating from rough strips and unprepared airports in remote locations. The high-wing layout protects engines and blades from debris, the power-to-weight ratio is higher than that of many comparable aircraft and the machine is rugged, requiring minimal ground support equipment..

Design and development

0

Ceiling

0

Combat RANGE

0

Km/h

Aircraft Speed

0

Max Crew

Antonov Company Antonov Design Bureau

Antonov Company Antonov Design Bureau
Antonov An-24 "Coke" Manufactured 1959–1979

General Info

Crew: 3
Capacity: 50 passengers
Length: 23.53 m (77 ft 2 in)
Wingspan: 29.20 m (95 ft 10 in)
Height: 8.32 m (27 ft 4 in)
Wing area: 74.98 m² (807.1 sq ft)

Powerplant

Empty weight: 13,300 kg (29,321 lb) Max takeoff weight: 21,000 kg (46,297 lb) Fuel capacity: 5,550 L (1,470 US gal; 1,220 imp gal) Powerplant: 2 × Ivchenko AI-24A turboprop engines, 1,900 kW (2,550 shp) each (eshp) Propellers: 4-bladed AV-72 constant-speed propellers, 3.90 m (12 ft 10 in) diameter

Performance

Cruise speed: 450 km/h (280 mph, 240 kn) at 6,000 m (20,000 ft)
Range: 2,400 km (1,500 mi, 1,300 nmi) with maximum fuel; 550 km (340 mi; 300 nmi) with maximum payload
Service ceiling: 8,400 m (27,600 ft)
Rate of climb: 1.91 m/s (375 ft/min)

Related development

- Aircraft of comparable role, configuration, and era

Special Links Antonov Company Antonov Design Bureau

Links to Youtube & Others

Due to its rugged airframe and good performance, the An-24 was adapted to perform many secondary missions such as ice reconnaissance and engine/propeller test-bed,.

Antonov Bureau
An-24 "Coke"

Production continues at China's Xi'an Aircraft Industrial Corporation which makes licensed,

Youtube Link

The main production line was at the Kyiv-Svyatoshino (later renamed "Aviant") aircraft production plant which built 985

Antonov Design Bureau
Antonov An-24 Coke
Manufactured 1959–1979

Antonov
AN-24 Coke

.

History Antonov Company Antonov Design Bureau
Antonov An-24 "Coke" Manufactured 1959–1979
