Role	Regional airliner, cargo aircraft
Manufacturer	Let Kunovice
First flight	16 April 1969
Introduction	1970
Status	In service
Produced	1971–present
Number built	1,200
Variants	Aircraft Industries L 410 NG

Development of the L-410 was started during the mid-1960s by the Czechoslovak aircraft manufacturer Let Kunovice. The company had decided to launch the project with awareness that the Soviet airline Aeroflot was actively seeking a turboprop-powered replacement for the Antonov An-2 biplane, which was viewed as a potentially lucrative opportunity for a suitable aircraft. Preliminary studies performed by Let centred around a design referred to as the L-400. In addition to its use as an airliner, equal attention was paid towards its suitability for the role of a cargo aircraft.

Design

The Let L-410 Turbolet is an unpressurized all-metal high-wing commuter aircraft. It is characterised by its relatively low maintenance and operating costs, as well as its adaptable design, which includes special interchangeable configurations. All models are equipped with a retractable undercarriage. The L-410 UVP-E features two hydraulic circuits, one being the primary and the other intended for emergencies; the main electrical system operates with 28V DC. The de-icing system is leading edge pneumatic deicers and electrical heating of propellers, cockpit windshields and pitot-static system heads. The maximum take-off weight of the L-410 UVP-E is 6400 kg with the possibility of an increase to 6,600 kg (14,600 lb) for the E9 and E20 variants, possessing a maximum seating capacity of between 17 and 19 passengers. The L-410 UVP-E is equipped with Avia V 510 five-blade propellers..

Aero Vodochody

Aero Vodochody
Aero Vodochody/Let Kunovice
Let L-410 Turbolet Regional airliner

General Info

Crew: 2
Capacity: 19 passengers / 1,800 kg (3,968 lb) payload
Length: 14.42 m (47 ft 4 in)
Wingspan: 19.98 m (65 ft 7 in)
Height: 5.97 m (19 ft 7 in)
Wing area: 34.86 m² (375.2 sq ft)

Powerplant

mpty weight: 4,200 kg
Max takeoff weight: 6,600 kg
Fuel capacity: 1,300 kg
Powerplant: 2 × General Electric H80-200 turboprop engines, 597 kW (801 hp) each

Performance

Cruise speed: 405 km/h max cruise
Range: 1,500 km (930 mi, 810 nmi) 1,800 kg (3,968 lb) payload, ISA, FL140, 45 min reserve
Endurance: Five hours and six minutes
Service ceiling: 8,382 m (27,500 ft)
Rate of climb: 8.5 m/s (1,670 ft/min)
Fuel consumption: 240 kg/h (529 lb/h)
Take-off run: 510 m
Landing run: 500 m (1,600 ft)

Armament

Special Links Aero Vodochody/Let Kunovice Let L-410 Turbolet Regional airliner

Links to Youtube & Others

Twin turboprop commuter airliner. First flight in 1969, in service since 1971 (L-420 since 1998). Czech successful commuter aircraft development. Built in a few versions. L-420 improved version with more powerful engines and higher weight. Also used by military as light tactical and utility transport aircraft. AYRES was owner of LET from 1998 until 2013.

Aero Vodochody
Let L-410 Turbolet

The L 410 is an all-metal, high-wing turboprop aircraft that is exceptionally reliable

Youtube Link

The L 410 is operated as a civilian aviation aircraft by commercial airlines, government agencies, the military and aviation clubs around world.
