The EL/W-2085 is an airborne early warning and control (AEW&C) multi-band radar system developed by Israel Aerospace Industries (IAI) and Elta Electronics Industries of Israel. Its primary objective is to provide intelligence to maintain air superiority and conduct surveillance. The system is currently in-service with Israel, Italy, and Singapore.

In 2005, the Israeli Air Force purchased five Gulfstream G550-based Eitam aircraft to serve as the new IDF platform for its newer generation of AEW systems. The new aircraft use the EL/W-2085 dual-band sensor suite, and are more capable and less expensive to operate than the older Boeing 707-based EL/M-2075. Extensive modifications were made to the Gulfstream's fuselage by IAI, such as the addition of protruding composite radomes, to house the radar arrays in conformal body modifications. Based at Nevatim Airbase

Design

Instead of using a rotodome, a moving radar found on some AEW&C aircraft, the EL/W-2085 uses an active electronically scanned array (AESA) – an active phased array radar. This radar consists of an array of transmit/receive (T/R) modules that allow a beam to be electronically steered, making a physically rotating rotodome unnecessary. AESA radars operate on a pseudorandom set of frequencies and also have very short scanning rates, which makes them difficult to detect and jam. Up to 1000 targets can be tracked simultaneously to a range of 243 nmi (450 km), while at the same time, multitudes of air-to-air interceptions or air-to-surface (includes maritime) attacks can be guided simultaneously. The radar equipment of the Israeli CAEW consists of each one L-band radar left and right sides on the fuselage and each one S-band antenna in nose and tail. The phased array allows positions of aircraft on operator screens to be updated every 2–4 seconds, rather than every 10 seconds as is the case on the rotodome AWACS.

Israel Aerospace Industries IAI EL/W-2085 AEW&C

Israel Aerospace Industries
IAI EL/W-2085 AEW&C

General Info

Crew: up to nine: two pilots and up to seven crew members according to mission including the mission crew commander (electronic warfare officer), weapon system officer (electronic warfare officer), mission crew supervisor (an experienced cryptologic linguist), analysis operators (linguists), one acquisition operator and/or an airborne maintenance technician.
Length: 96 ft 5 in (29.39 m)
Wingspan: 93 ft 6 in (28.50 m)
Height: 25 ft 10 in (7.87 m)

Powerplant

Empty weight:(21,909 kg)
Max takeoff weight: (44,452 kg)
Fuel capacity: 41,300 lbs
Powerplant: 2 × Rolls Royce BR700-710 C4-11 turbofan, 15,385 lbf (68.44 kN) thrust each

Performance

Range: 6,750 nmi (7,770 mi, 12,500 km) High Speed Cruise: M0.85 at 41,000 ft (12,000 m) Long Range Cruise: M0.80 at 41,000 ft (12,000 m) Maximum Mach Operating (MMO): M0.885 at 41,000 ft (12,000 m) Service ceiling: 51,000 ft (16,000 m)

Armament
