Russian Aircraft  "Mig"
MiG-29 Fulcrum


A Russian Air Force MiG-29S
Role Air superiority fighter, multirole fighter
National origin Soviet Union
Design group Mikoyan
First flight 6 October 1977
Introduction August 1983
Status In service
Primary users Russian Aerospace Forces
Indian Air Force
Uzbekistan Air and Air Defence Forces
Ukrainian Air Force
Produced 1981–present
Number built >1,600
Variants Mikoyan MiG-29M
Mikoyan MiG-29K
Mikoyan MiG-35
.
History Russian Aircraft Corporation "Mig"
Mikoyan MiG-29 NATO reporting name: Fulcrum



The Mikoyan MiG-29 (Russian: Микоян МиГ-29; NATO reporting name: Fulcrum) is a twin-engine fighter aircraft designed in the Soviet Union. Developed by the Mikoyan design bureau as an air superiority fighter during the 1970s, the MiG-29, along with the larger Sukhoi Su-27, was developed to counter new U.S. fighters such as the McDonnell Douglas F-15 Eagle and the General Dynamics F-16 Fighting FalconThe MiG-29 entered service with the Soviet Air Forces in 1983.

Design

MiG-29UB of the Swifts aerobatic team

Sharing its origins in the original PFI requirements issued by TsAGI, the MiG-29 has broad aerodynamic similarities to the Sukhoi Su-27, but with some notable differences. The MiG-29 has a mid-mounted swept wing with blended leading-edge root extensions (LERXs) swept at around 40°; there are swept tailplanes and two vertical fins, mounted on booms outboard of the engines. Automatic slats are mounted on the leading edges of the wings; they are four-segment on early models and five-segment on some later variants. On the trailing edge, there are maneuvering flaps and wingtip ailerons

The sketch of the MiG-29 performing the super maneuver, the Pugachev's Cobra.
MiG-29SMT at the 2011 MAKS


0

Km

Ceiling

0

Km

Combat RANGE

0

Mach

Aircraft Speed

0

Max Crew

element
element
Voronezh Aircraft Production Association

Russian Aircraft Corporation "Mig"
Mikoyan MiG-29 NATO reporting name: Fulcrum

1

General Info

          • Crew: 1
          • Length: 17.32 m (56 ft 10 in)
          • Wingspan: 11.36 m (37 ft 3 in)
          • Height: 4.73 m (15 ft 6 in)
          • Wing area: 38 m2 (410 sq ft)
2

Powerplant


          • Empty weight: 11,000 kg
          • Gross weight: 14,900 kg
          • Max takeoff weight: 18,000 kg
          • Fuel capacity: 3,500 kg internal
          • Powerplant: 2 × Klimov RD-33 afterburning turbofan engines, 49.42 kN (11,110 lbf) thrust each [338] dry, 81.58 kN (18,340 lbf) with afterburner
plane
3

Performance

    • Maximum speed: 2,450 km/h (1,520 mph, 1,320 kn) at high altitude
    • Maximum speed: Mach 2.3+
    • Range: 1,430 km (890 mi, 770 nmi) with maximum internal fue
    • Combat range: 700–900 km (430–560 mi, 380–490 nmi) with 2 x R-27s, 4 x R-73s at high altitude
    • Service ceiling: 18,000 m (59,000 ft)
    • g limits: +9

4

Armament

.
Special Links Russian Aircraft Corporation "Mig" Mikoyan MiG-29 NATO reporting name: Fulcrum

Links to Youtube & Others

Armament for the MiG-29 includes a single GSh-30-1 30 mm (1.18 in) cannon in the port wing root. This originally had a 150-round magazine, which was reduced to 100 rounds in later variants, which only allows a few seconds of firing before running out of ammo. Original production MiG-29 aircraft cannot fire the cannon when carrying a centerline fuel tank as it blocks the shell ejection port. This was corrected in the MiG-29S and later versions.

Russian Aircraft Mig
MiG-29 Fulcrum

The cockpit features a conventional centre stick and left hand throttle controls. The pilot sits in a Zvezda K-36DM ejection seat.

interior

Youtube Link

The baseline MiG-29 9.12 has a Phazotron RLPK-29 radar fire control system which includes the N019 Sapfir 29 look-down/shoot-down coherent pulse-Doppler radar and the Ts100.02-02 digital computer.

interior
Aircrafttotal : Aircraft

Read more in Russian Aircraft Corporation "Mig"  Mikoyan MiG-29 Fulcrum

.
