The de Havilland DH.98 Mosquito is a British twin-engined, shoulder-winged, multirole combat aircraft, introduced during the Second World War. Unusual in that its frame was constructed mostly of wood, it was nicknamed the "Wooden Wonder",[4] or "Mossie".[5] Lord Beaverbrook, Minister of Aircraft Production, nicknamed it "Freeman's Folly", alluding to Air Chief Marshal Sir Wilfrid Freeman, who defended Geoffrey de Havilland and his design concept against orders to scrap the project.[6] In 1941, it was one of the fastest operational aircraft in the world.

By the early to mid-1930s, de Havilland had built a reputation for innovative high-speed aircraft with the DH.88 Comet racer. Later, the DH.91 Albatross airliner pioneered the composite wood construction used for the Mosquito. The 22-passenger Albatross could cruise at 210 mph (340 km/h) at 11,000 ft (3,400 m), faster than the Handley Page H.P.42 and other biplanes it was replacing. The wooden monocoque construction not only saved weight and compensated for the low power of the de Havilland Gipsy Twelve engines used by this aircraft, but also simplified production and reduced construction time

The design was noted for light and effective control surfaces that provided good manoeuvrability, but required that the rudder not be used aggressively at high speeds. Poor aileron control at low speeds when landing and taking off was also a problem for inexperienced crews.[64] For flying at low speeds, the flaps had to be set at 15°, speed reduced to 200 mph (320 km/h), and rpm set to 2,650. The speed could be reduced to an acceptable 150 mph (240 km/h) for low-speed flying.[65] For cruising, the optimum speed for obtaining maximum range was 200 mph (320 km/h) at 17,000 lb (7,700 kg) weight.

Famous aircraft The de Havilland Aircraft Company Limited

de Havilland Company
DH.98 Mosquito

General characteristics

Crew: Two: pilot, bomb aimer/navigator
Length: 44 ft 6 in (13.56 m)
Wingspan: 54 ft 2 in (16.51 m)
Height: 17 ft 5 in (5.31 m)
Wing area: 454 sq ft (42.2 m²)

Powerplant

- Empty weight: 14,300 lb (6,486 kg)
- Gross weight: 18,100 lb (8,210 kg)
- Max takeoff weight: (11,340 kg)
- Powerplant: 1 × Rolls-Royce Merlin 76 V-12 liquid-cooled piston engine, 1,710 hp (1,280 kW) driving the left propeller
- Powerplant: 1 × Rolls-Royce Merlin 77 V-12 liquid-cooled piston engine, 1,710 hp (1,280 kW) fitted with a blower for cabin pressurisatio

Specifications

Maximum speed: 415 mph (668 km/h, 361 kn) at 28,000 ft (8,500 m)
Range: 1,300 mi (2,100 km, 1,100 nmi)
Service ceiling: 37,000 ft (11,000 m)
Rate of climb: 2,850 ft/min (14.5 m/s)
Wing loading: 39.9 lb/sq ft (195 kg/m²)

Armament

Armament

Guns: 4 x 7.7 mm Browning machine guns, 4 x 20 mm Hispano cannons
Bombs: 4,000 lb (1,800 kg)

Avionics

GEE radio-navigation
