General Info

Raytheon RTX
AIM-7 Sparrow MRAAM

Type Medium-range, semi-active radar homing air-to-air missile
Place of origin United States
Service history
In service 1958–present
Used by Australia, Canada, Egypt, Greece, Iran, Iraq, Israel, Italy, Japan, Jordan, Kuwait, Malaysia, Saudi Arabia, Singapore, South Korea, Spain, Taiwan, Turkey, United Kingdom, United States
Wars Vietnam War
Iran-Iraq War
Gulf War
Production history
Manufacturer Raytheon
Unit cost $125,000
Produced AIM-7D: 1959
AIM-7F: 1976AIM-7M: 1982
No. built >70,000
Variants Sparrow I: AIM-7A
Sparrow II: AIM-7B
Sparrow III: AIM-7C, AIM-7D, AIM-7E, AIM-7E2/Skyflash/Aspide, AIM-7F, AIM-7M, AIM-7P, RIM-7M, AGM-45
.
History Raytheon RTX Corporation AIM-7 Sparrow
is a medium-range air-to-air missile In service 1959–present



The AIM-7 Sparrow (Air Intercept Missile) is an American medium-range semi-active radar homing air-to-air missile operated by the United States Air Force, United States Navy, United States Marine Corps, and various other air forces and navies. Sparrow and its derivatives were the West's principal beyond visual range (BVR) air-to-air missile from the late 1950s until the 1990s. It remains in service, although it is being phased out in aviation applications in favor of the more advanced AIM-120 AMRAAM. The early Sparrow was intended primarily for use against larger targets, especially bombers, and had numerous operational limitations in other uses. Against smaller targets, the need to receive a strong reflected radar signal made it difficult to achieve lock-on at the missile's effective range. As the launching aircraft's own radar needed to be pointed at the target throughout the engagement, this meant that in fighter-vs-fighter combat the enemy fighter would often approach within the range of shorter-range infrared homing missiles while the launching aircraft had to continue flying towards its target. Additionally, early models were only effective against targets at roughly the same or higher altitudes, below which reflections from the ground became a problem.

Development

Sparrow I

Sparrow I's during tests on a Douglas F3D Skyknight in the early 1950s

The Sparrow emerged from a late-1940s United States Navy program to develop a guided rocket weapon for air-to-air use. In 1947 the Navy contracted Sperry to build a beam-riding version of a standard 5-inch (127 mm) HVAR, the standard unguided aerial rocket, under Project Hotshot. The weapon was initially dubbed KAS-1, then AAM-2, and — from 1948 on — AAM-N-2. The airframe was developed by the Douglas Aircraft Company. The diameter of the HVAR proved to be inadequate for the electronics, leading Douglas to expand the missile's airframe to 8-inch (203 mm) diameter. The prototype weapon began unpowered flight tests in 1947, and made its first aerial interception in 1952.

After a protracted development cycle the initial AAM-N-2 Sparrow entered limited operational service in 1954 with specially modified Douglas F3D Skyknight all-weather carrier night fighters. In 1956, they were joined by the McDonnell F3H-2M Demon and Vought F7U Cutlass fighter aircraft. Compared to the modern versions, the Sparrow I was more streamlined and featured a bullet-shaped airframe with a long pointed nose.

Kill count summary
Category USAF USN Combined
An-2s 2 2
MiG-17s 8 5 13
MiG-19s 4 4
MiG-21s 38 3 41
Total 50 10 60


40
Kg

Warhead Weight

70
Km

Max Range

2.5+
Mach

Performance

1959
Introduction

Introduction

element
element
Raytheon RTX Corporation

Raytheon RTX Corporation AIM-7 Sparrow is a medium-range air-to-air missile In service 1959–present

1
        • AIM-7 Sparrow Raytheon SRAAM

          Specifications
          Mass 510 lb (230 kg)
          Length 12 ft (3.7 m)
          Diameter 8 in (200 mm)
          Wingspan 2 ft 8 in (0.81 m) (AIM-7A/B)
          Warhead High explosive blast-fragmentation
          AIM-7C/D/E: 65 pounds (29 kg)AIM-7F/M: 88 pounds (40 kg)

          Operationalrange AIM-7C: 26 km (14 nmi)
          AIM-7D: 44 km (24 nmi)
          AIM-7E/E2: 50 km (27 nmi)AIM-7F/M/P: 70 km (38 nmi
plane
Special Links Raytheon RTX Corporation AIM-7 Sparrow is a medium-range air-to-air missile In service 1959–present

Links to Youtube & Others

The Air Intercept Missile (AIM)-7 Sparrow is a supersonic, medium-range air-to-air missile. The development of this beyond visual range (BVR) missile started as a project called “Hotshot” in 1946 and was intended to design a missile which was capable of intercepting enemy targets at medium range

Raytheon RTX
AIM-7 Sparrow MRAAM

The AIM-7 Sparrow is a radar-guided, air-to-air missile with a high-explosive warhead

interior

Youtube Link

The missile has four major sections: guidance section, warhead, control and rocket motor. It has a cylindrical body with four wings at mid-body and four tail fins.

interior
