The EC155 B features a completely redesigned cabin providing 30% more passenger space than previous Dauphin helicopter models, plus a 130% increase in baggage hold volume. Other major improvements include a five-blade Spheriflex composite main rotor combined with the familiar shrouded Fenestron tail rotor to reduce vibration levels significantly. The EC155 B is powered by two 635 kW (851 shp) Turbomeca Arriel 2C1 turboshaft engines which feature a dual-channel Full Authority Digital Engine Control (FADEC) system. The EC155 B1 features uprated 697 kW (935 shp) Arriel 2C2s. The helicopter can be fitted with an anti-icing system to enable the aircraft to operate in very cold climates. The all-glass cockpit is equipped with an 'Avionique Nouvelle' integrated digital flight control system featuring Eurocopter's Vehicle and Engine Management Display (VEMD), which utilizes active matrix liquid crystal displays. The EC155 is also equipped with a four-axis digital autopilot, coupled to the engine FADECs for full-envelope protection, and is offered with a Health and Usage Monitoring System (HUMS).
Ceiling
Range
Aircraft Speed
Max Crew
|
In March 1999, deliveries of the EC155 B commenced, the German Federal Police became the first operator of the type. Between March 1999 and June 2003, roughly 50 EC155 Dauphins were sold, mainly to VIP and off-shore customers
The LCH is to enter service in 2020, and the LAH will follow in 2022 to replace the MD 500 Defender and AH-1J/S Cobra.
In 2015, Airbus Helicopters and Korean Aerospace Industries (KAI) formed an agreement to transfer principle manufacturing activity for the EC155 to South Korea
