History Beech Aircraft Corporation
Beechcraft G36 Bonanza
The Beechcraft Bonanza is an American general aviation aircraft introduced in 1947 by Beech Aircraft Corporation of Wichita, Kansas. The six-seater, single-engined aircraft is still produced by Beechcraft and has been in continuous production longer than any other aircraft in history. More than 17,000 Bonanzas of all variants have been built, produced in both distinctive V-tail and conventional tail configurations; early conventional-tail versions were marketed as the Debonair
Design and development
At the end of World War II, two all-metal light aircraft emerged, the Model 35 Bonanza and the Cessna 195, that represented very different approaches to the premium end of the postwar civil-aviation market. With its high-wing, seven-cylinder radial engine, fixed tailwheel undercarriage, and roll-down side windows, the Cessna 195 was a continuation of prewar technology. The Bonanza, however, featured an easier-to-manage, horizontally opposed, six-cylinder engine, retractable tricycle undercarriage (although the nosewheel initially was not steerable, but castering) and low-wing configuration.
Variants
- H35
- (1957) Powered by a 240 hp (180 kW) Continental O-470-G engine, and with modified structure. 464 built.
- J35
- (1958) Powered by a 250 hp (190 kW) fuel injected Continental IO-470-C engine. 396 built.
- K35
- (1959) Increased fuel load, optional fifth seat and increased takeoff weight, 436 built.
- M35
- (1960) Similar to K35, 400 built.
Photo Gallery
Beech Aircraft Corporation
Beechcraft G36 Bonanza
Beech Aircraft Corporation
Beechcraft G36 Bonanza
General Info
-
-
-
- Crew: one
- Capacity: five passengers
- Length: 27 ft 6 in (8.38 m)
- Wingspan: 33 ft 6 in (10.21 m)
- Height: 8 ft 7 in (2.62 m)
-
-
Powerplant
-
- Empty weight: 2,517 lb (1,142 kg)
- Gross weight: 3,650 lb (1,656 kg)
- Powerplant: 1 × Continental IO-550-B , 300 hp (220 kW)
- Propellers: three-bladed Hartzell Propeller, 6 ft 8 in (2.03 m) diameter
Performance
- Cruise speed: 326 km/h
- Range: 1,326 km) with full passenger load
- Ferry range: 1,720 km)
- Service ceiling: (5,600 m)
.
Links to Youtube & Others
The V-tail design gained a reputation as the "forked-tail doctor killer", due to crashes by overconfident wealthy amateur pilots, fatal accidents, and in-flight breakups. "Doctor killer" has sometimes been used to describe the conventional-tailed version, as well
Beechcraft Aircraft
Beechcraft G36 Bonanza
The Beechcraft Bonanza is an American general aviation aircraft introduced in 1947 by Beech Aircraft Corporation of Wichita, Kansas.
Youtube Link
The Bonanza family eventually comprised three major variants: Model 35 Bonanza (1947–1982; V-tail) Model 33 Debonair or Bonanza (1960–1995; conventional tail) Model 36 Bonanza (1968–present; a stretched Model 33)
