Embraer ERJ 190


General information
Type	Regional jet

The Embraer E-Jet family is a series of four-abreast, narrow-body, short- to medium-range, twin-engined jet airliners designed and produced by Brazilian aerospace manufacturer Embraer.

The E-Jet was designed as a complement to the preceding ERJ family, Embraer's first jet-powered regional jet. Designed to carry between 66 and 124 passengers, it was larger than any prior aircraft built by the company. The project's existence was revealed in early 1997 and was formally introduced at the Paris Air Show two years later. On 19 February 2002, the first prototype E-Jet conducted its maiden flight; later that year, quantity production of the type commenced. In early March 2004, the first E170 deliveries were made to LOT Polish Airlines. Larger versions of the aircraft, the E190 and E195, debuted later in 2004, while a slightly stretched version of the E170 was introduced in mid-2005 as the E175.

Design

The Embraer E-Jet family is composed of two main commercial families and a business jet variant. The smaller E170 and E175 make up the base model aircraft, while the E190 and E195 are stretched versions, being powered by different engines and furnished with larger wing, horizontal stabilizer and landing gear structures. From the onset, the E-Jet had been designed to be stretched.^[13] The E170 and E175 share 95% commonality, as do the E190 and E195; the two families share near 89% commonality, maintaining identical fuselage cross-sections and avionics fitouts. The E190 and E195 possess capacities similar to the initial versions of the McDonnell Douglas DC-9 and Boeing 737. All members of the E-Jet family are available in baseline, long range (LR), and advanced range (AR) models, the latter being intended for long routes with limited passenger numbers.

Embraer ERJ series Airliner

Embraer S.A. Airliner Series
Embraer E-190-E2 Series. E-Jet E2 family

General characteristics

Cabin	E170
Flight crew	2 pilots
Single-class seats	72@32" - 78@30-33"
Dual-class seats	66 (6F@40", 60Y@32")
Height × width	2.00 m × 2.74 m (6 ft 7 in × 9 ft 0 in)
Dimensions	E170
Length	29.90 m (98 ft 1 in)
Wingspan	26.01 m (84 ft 4 in) (E170/E75S) / 28.65 m (94 ft) (E75L)

Service name

Powerplant	E170 / E175
Turbofans (2×)	GE CF34-8E
Thrust	14,200 lbf (63 kN)

Specifications

Performance	E170
Max. speed	Mach .82 (470 kn; 871 km/h; 541 mph) @ 41,000 ft (12,000 m)
Cruise	Mach .75 (430 kn; 797 km/h; 495 mph)
Range	2,150 nmi (3,982 km; 2,470 mi)

Avionics

Embraer ERJ 190

Honeywell Primus Epic

Special Links Boeing Millitary Airplanes Embraer VIP Airliner

Links to Youtube & Others

On 19 February 2002, the first prototype performed its maiden flight, marking the beginning of a multi-year flight test campaign involving a total of six prototypes.

Embraer ERJ-170/175/190/195 Series

The Embraer E-Jet family is a series of four-abreast, narrow-body, short- to medium-range, twin-engined jet airliners

Youtube Link

On 19 February 2002, the first prototype performed its maiden flight, marking the beginning of a multi-year flight test campaign involving a total of six prototypes

Embraer S.A.
Embraer ERJ-170/175/190/195 Series.
First Flight 19 February 2002
Produced 2001–Present

Embraer ERJ-170/175/190/195 Series.

.

History Embraer S.A. is a Brazilian multinational
aerospace corporation.
Embraer E-190-E2 Series. E-Jet E2 family
First Flight 19 February 2002 Produced 2001–Present
