Piper aircraft, Inc.
Piper PA-31 Navajo is an utility aircraft built between 1967 and 1984 by Piper Aircraft.
Piper aircraft,Inc.
Piper PA-31 Navajo
|
|||||||||||||||||||||||
|
|
|
|
|---|
.
History Piper aircraft, Inc.
Piper PA-31 Navajo
is an utility aircraft built between 1967 and 1984 by Piper Aircraft.
The Piper PA-31 Navajo is a family of twin-engined utility aircraft designed and built by Piper Aircraft for small cargo and feeder airlines, and as a corporate aircraft. Production ran from 1967 to 1984. It was license-built in a number of Latin American countries.
Development
Early Navajo with two-bladed propellers and two-part entry door
In 1962, Piper began developing a six- to eight-seat twin-engined corporate and commuter transport aircraft under the project name Inca, at the request of company founder William T. Piper. Looking like a scaled-up PA-30 Twin Comanche, the PA-31 made its first flight on 30 September 1964, and was announced later that year. It is a low-wing monoplane with a conventional tail, powered by two 310 hp (231 kW) Lycoming TIO-540-A turbocharged engines in "tiger shark" cowlings, a feature shared with the Twin Comanche and the PA-23 Aztec.
-
Design and development
Early Navajo with two-bladed propellers and two-part entry door The PA-31 series was manufactured under licence in several countries from kits of parts supplied by Piper Chincul SACAIFI in Argentina assembled most of the series as the PA-A-31, PA-A-31-325, PA-A-31P and PA-A-31-350 and Aero Industrial Colombiana SA (AICSA) in Colombia assembled PA-31, PA-31-325 and PA-31-350 aircraft. The PA-31-350 Chieftain was also assembled under licence in Brazil by Embraer as the EMB 820C Navajo. In 1984, Embraer subsidiary company Indústria Aeronáutica Neiva began converting Embraer EMB 820Cs by installing Pratt & Whitney Canada PT6 turboprop engines; Neiva called the converted aircraft the Carajá
Variants
commuter cabin - PA-31 Navajo
- Initial production version, also known unofficially as the PA-31-310.
- PA-31-300 Navajo
- Variant of the Navajo with normally aspirated engines; 14 built.
- PA-31 Navajo B
- Marketing name for 1971 improved variant with 310 hp (231 kW) Lycoming TIO-540-E turbo-charged piston engines, new airconditioning and optional pilot access door and optional wide utility door
_at_Essendon_Airport.jpg)
.jpg)
0
KmCeiling
0
KmMAX RANGE
0
Km.hAircraft Speed
0
Max Crew
Photo Gallery
Piper aircraft, Inc.
Piper PA-31 Navajo
is an utility aircraft built between
1967 and 1984 by Piper Aircraft.
Piper aircraft, Inc.
Piper PA-31 Navajo
is an utility aircraft built between
1967 and 1984 by Piper Aircraft.
General characteristics
- Crew: 1 or 2
- Capacity: 5 to 7 passengers
- Length: 32 ft 7+1⁄2 in (9.94 m)
- Wingspan: 40 ft 8 in (12.40 m)
- Height: 13 ft 0 in (3.96 m)
- Wing area: 229 sq ft (21.3 m2)
-
Powerplant
- Empty weight: (1,783 kg)
- Max takeoff weight: (2,948 kg)
- Fuel capacity: 190 US gal (160 imp gal; 720 L) total, 187 US gal (156 imp gal; 710 L) useable
- Powerplant: 2 × Lycoming TIO-540-A air-cooled six-cylinder horizontally opposed piston engine, 310 hp (230 kW) each
Specifications
- Maximum speed: 261 mph (420 km/h, 227 kn) at 15,000 ft (4,600 m)
- Cruise speed: 238 mph (383 km/h, 207 kn) at 20,000 ft (6,100 m) (econ. cruise)
- Range: 1,165 mi (1,875 km, 1,012 nmi) at 20,000 ft (6,100 m) (econ. cruise speed)
- Service ceiling: 26,300 ft (8,000 m)
Links to Youtube & Others
A larger and more powerful variant of the Navajo,
the Piper PA-31-350 Navajo Chieftain is fast, efficient and perfect for short-haul trips.
Piper aircraft, Inc.
Piper PA-31 Navajo
The Navajo family is popular with air charter companies, small feeder airlines and commuter air carriers in many countries,
Youtube Link
The PA-31 Navajo was also formerly operated in scheduled passenger airline service in the U.S. in 1968 by Air West, the predecessor of Hughes Airwest which in turn subsequently became an all-jet airline
