Bombardier Aerospace
CRJ700 series is a family of
regional jet airliners
Manufactured 1999–2020
Bombardier AerospaceCRJ 700 Series
.jpg) |
|
| General information | |
|---|---|
| Type | Regional jet |
| National origin | Canada |
| Manufacturer | Bombardier Aviation |
| Status | In service |
| Primary users | SkyWest AirlinesPSA Airlines Endeavor Air GoJet Airlines |
| Number built | 924 |
| History | |
| Manufactured | 1999–2020 |
| Introduction date | 2001 |
| First flight | 27 May 1999 |
| Developed from | Bombardier CRJ100/200 |
.
History Bombardier Bombardier CRJ700 series is a family of regional jet airliners Manufactured 1999–2020
The Bombardier CRJ700 series is a family of regional jet airliners that were designed and manufactured by Canadian transportation conglomerate Bombardier (formerly Canadair). Officially launched in 1997, the CRJ700's maiden flight took place on 27 May 1999; it was soon followed by the stretched CRJ900 variant. Several additional variants of the type were subsequently introduced, including the elongated CRJ1000 and the CRJ550 and CRJ705, which were modified to comply with scope clauses. The CRJ program was acquired by the Japanese corporation Mitsubishi Heavy Industries in 2020, which ended production of the aircraft.
Their design was derived from the smaller CRJ100 and 200 airliners, the other members of the Bombardier CRJ aircraft family. During the 1990s, Bombardier initiated development on the CRJ-X, a program to produce enlarged derivatives of its popular CRJ100/200 family. During its lifetime, competitors included the British Aerospace 146, the Embraer E-Jet family, the Fokker 70, and the Fokker 100.
Development
Origins
During
the early 1990s, Bombardier Aerospace became interested in developing larger variants of the CRJ100/200 series; associated design work commenced in 1994. The CRJ-X, as the new range was initially designated, sought to compete with larger regional jets such as the Fokker 70/Fokker 100 or the BAe 146 family. The CRJ-X featured a stretched fuselage, a lengthened wing, and up-rated General Electric CF34-8C engines, while maintaining a common type-rating with the basic CRJ. Leading-edge extensions and high-lift slats improved the wing performance, other aerodynamic changes included an enlarged horizontal tailfin. By March 1995, low-speed wind tunnel testing confirmed a 2,830 km (1,530 nm) range in the 74-seat North American configuration and 2,350 km in the 72-seat European configuration. First deliveries were planned for 1999.
Variants
CRJ700
.jpg)
Design work on the CRJ700 by Bombardier started in 1995, and the program was officially launched in January 1997. The CRJ700 is a stretched derivative of the CRJ200. The CRJ700 features a new wing with leading-edge slats and a stretched and slightly widened fuselage, with a lowered floor. Its first flight took place on 27 May 1999. The aircraft model is listed as CL-600-2C10 on the TCCA, FAA, and EASA Type Certificates. The CRJ700 first entered commercial service with Brit Air in 2001
Bombardier CRJ900
The CRJ900 is a stretched 76- to 90-seat version of the CRJ700. Internally designated as the RJX, the first CRJ900 (C-FRJX) was modified from the prototype CRJ700 by adding longer fuselage plugs fore and aft of the wings. It was later converted into the prototype CRJ1000 by replacing the fuselage plugs with longer plugs.
0
KmCeiling
0
KmCombat RANGE
0
MachAircraft Speed
0
Max Crew
Photo Gallery
Bombardier Bombardier CRJ700 series is a family of regional jet airliners
Manufactured 1999–2020
Bombardier Bombardier CRJ700 series is a family of regional jet airliners
Manufactured 1999–2020
General Info
-
-
-
Exterior
- Exterior Height
: 24 ft 10 in - Wing Span
: 76 ft 3 in - Length
: 106 ft 1 in
Interior
- Cabin Height
: 6 ft 2 In - Cabin Width
: 8 ft 10 In
Occupancy
- Crew
: 2 - Passengers
: 66-78
- Exterior Height
-
-
Powerplant
-
-
-
- Engines
: 2 - Engine Mfg
: General Electirc - Engine Model
: GE CF34-8C5B1
- Engines
-
-
.webp)
Performance
-
- Max Speed
: 473 kts - Normal Cruise
: 447 kts
- Max Speed
-
-
Operating Weights
- Max T/O Weight
: 75000 Lb - Operating Weight
: 44245 Lb - Empty Weight
: 43200 Lb - Fuel Capacity
: 19595 Lb - Payload Useful
: 18800 Lb - Max Payload
: 18055 Lb
- Max T/O Weight
-
.
Links to Youtube & Others
As of July 2018, 290 CRJ700 aircraft (all variants), 425 CRJ900 aircraft (all variants), and 62 CRJ1000 aircraft were in airline service with SkyWest Airlines (123), Endeavor Air (112), PSA Airlines (95), Mesa Airlines (84), GoJet Airlines (54), ExpressJet Airlines (39), Lufthansa CityLine (37), China Express Airlines (36), Jazz Aviation LP (35), Scandinavian Airlines (26), HOP! (25), Air Nostrum (23), Envoy Air (20), Garuda Indonesia (18), and other operators with fewer aircraft of the type.
Bombardier Bombardier CRJ700 series/CRJ1000
The CRJ705 was a variant of the CRJ900 regional jet limited by type certification to just 75 seats,
Youtube Link
According to Bombardier, by 2015, the CRJ series accounted for over 20% of all jet departures in North America; globally, the family operated in excess of 200,000 flights per month.
